| Vonkajżí priemer [mm] | 256,0 |
| Hrúbka brzd. kotúča (mm) | 24,0 |
| Minimálna hrúbka (mm) | 21,5 |
| Typ brzdového kotúča | vetraný |
| Povrch | potiahnutá |
| Počet dier | 4 |
| Rozstupová krużnica Ø [mm] | 114,3 |
| Výżka [mm] | 45,5 |
| Centrovací priemer [mm] | 69,0 |
| Vnútorný priemer [mm] | 145,0 |
| Vŕtanie Ø [mm] | 12,6 |
| Značka | Číslo |
|---|---|
| ATE | 424136 |
| ATE | 24.0124-0136.1 |
| BENDIX | 561926B |
| BOSCH | 0 986 478 531 |
| BOSCH | 0 986 478 897 |
| BOSCH | 0 986 478 652 |
| BRADI | 1.3033.2.6 |
| BRADI | 1.6026.2.4 |
| BRECO | BS 8275 |
| BRECO | BS 8078 |
| BREMBO | 09.7043.10 |
| BREMBO | 09.5640.10 |
| BREMBO | 09.9617.11 |
| BREMBO | 09.5640.75 |
| BREMBO | 09.9617.10 |
| BREMBO | 09.5640.14 |
| CAR | 142.670 |
| CAR | 142.839 |
| CIFAM | 800-461 |
| CIFAM | 800-653 |
| DELPHI | BG3116 |
| DELPHI | BG2763 |
| DELPHI | BG3202 |
| FEBI BILSTEIN | 14924 |
| FEBI BILSTEIN | 10892 |
| FERODO | DDF885 |
| FERODO | DDF658 |
| FTE | BS7044 |
| FTE | BS4666 |
| GRAF | DF29461 |
| GRAF | DF29653 |
| HELLA | 8DD 355 105-451 |
| HELLA PAGID | 8DD 355 105-451 |
| HERTH+BUSS JAKOPARTS | J3305022 |
| HERTH+BUSS JAKOPARTS | J3300326 |
| HYUNDAI | 51712-M2000 |
| JURID | 561926J |
| KIA | 51712-M2000 |
| METELLI | 23-0461 |
| METELLI | 23-0653 |
| MGA | D1261 |
| MGA | D1354 |
| MINTEX | MDC856 |
| MITSUBISHI | MR205584 |
| MITSUBISHI | MB928995 |
| MITSUBISHI | MR128153 |
| MITSUBISHI | MB407639 |
| MITSUBISHI | MR205585 |
| NIPPARTS | J3300326 |
| NIPPARTS | J3305022 |
| NK | 203010 |
| PAGID | 54023 |
| PEX | 14.0359 |
| PEX | 14.0666 |
| PEX | 14.0372 |
| PILENGA | V620 |
| PILENGA | V609 |
| QUINTON HAZELL | BSF4666 |
| QUINTON HAZELL | BDC4775 |
| QUINTON HAZELL | BSF4886 |
| QUINTON HAZELL | BDC4666 |
| QUINTON HAZELL | BSF4775 |
| QUINTON HAZELL | BDC4886 |
| QUINTON HAZELL | BDC4330 |
| QUINTON HAZELL | 6394.10 |
| REMSA | 6394.10 |
| REMSA | 6394.11 |
| ROADHOUSE | 6394.10 |
| ROADHOUSE | 6394.11 |
| ROULUNDS BRAKING | D2307 |
| ROULUNDS BRAKING | D2497 |
| TEXTAR | 98200 0829 0 1 |
| TEXTAR | 92103903 |
| TEXTAR | 92082900 |
| TRW | DF4081BP |
| TRW | DF4081 |
| TRW | DF2798 |
| TRW | DF1443 |
| VALEO | 186475 |
| VALEO | 186648 |
| VOLVO | 30872926 |
| ZIMMERMANN | 380.2157.50 |
| ZIMMERMANN | 380.2157.00 |
| Model | Rok | Kód motora | KW | CCM |
|---|---|---|---|---|
HYUNDAI |
||||
HYUNDAI SANTAMO |
||||
| 2.0 | 1998 - 2002 | G4CP | 77 | 1997 |
| 2.0 16V | 1999 - 2002 | G4JP | 102 | 1997 |
| 2.0 16V 4x4 | 1999 - 2002 | G4CP-D | 102 | 1997 |
KIA |
||||
KIA JOICE (MTE1P) |
||||
| 2.0 | 2000 - 2003 | G4CP | 102 | 1997 |
| 2.0 | 2001 - 2003 | G4CP | 88 | 1997 |
MITSUBISHI |
||||
MITSUBISHI SPACE STAR Großraumlimousine (DG_A) |
||||
| 1.3 16V (DG1A) | 1998 - 2004 | 4G13 (16V) | 63 | 1299 |
| 1.3 16V (DG1A) | 1998 - 2004 | 4G13 (16V) | 61 | 1299 |
| 1.3 16V (DG1A) | 2000 - 2004 | 4G13 (16V) | 60 | 1299 |
| 1.6 | 2001 - 2004 | 4G92 (SOHC 16V) | 72 | 1597 |
| 1.6 16V (DG3A) | 2001 - 2004 | 4G18 | 72 | 1584 |
| 1.8 GDI (DG5A) | 1998 - 2004 | 4G93 (GDI) | 90 | 1834 |
| 1.8 GDI (DG5A) | 1998 - 2004 | 4G93 (GDI) | 87 | 1834 |
| 1.8 MPI (DG5A) | 2002 - 2004 | 4G93 (DOHC 16V) | 82 | 1834 |
| 1.9 DI-D (DG4A) | 2001 - 2004 | F9Q1 | 75 | 1870 |
| 1.9 DI-D (DG4A) | 2002 - 2004 | F9Q2 | 85 | 1870 |
MITSUBISHI CARISMA (DA_) |
||||
| 1.6 (DA1A) | 1995 - 2006 | 4G92 (SOHC 16V) | 66 | 1597 |
| 1.6 (DA1A) | 1997 - 2006 | 4G92 (SOHC 16V) | 73 | 1597 |
| 1.8 (DA2A) | 1995 - 1997 | 4G93 (SOHC 16V) | 85 | 1834 |
| 1.8 16V GDI (DA2A) | 1997 - 2006 | 4G93 (GDI) | 92 | 1834 |
| 1.8 MSX - 16V (DA2A) | 1995 - 1997 | 4G93 (DOHC 16V) | 103 | 1834 |
| 1.9 TD (DA4A) | 1996 - 2000 | F8QT | 66 | 1870 |
MITSUBISHI CARISMA Stufenheck (DA_) |
||||
| 1.6 (DA1A) | 1996 - 2006 | 4G92 (SOHC 16V) | 66 | 1597 |
| 1.6 (DA1A) | 1997 - 2006 | 4G92 (SOHC 16V) | 73 | 1597 |
| 1.8 (DA2A) | 1996 - 1997 | 4G93 (SOHC 16V) | 85 | 1834 |
| 1.8 16V GDI (DA2A) | 1997 - 2006 | 4G93 (GDI) | 92 | 1834 |
| 1.9 TD (DA4A) | 1996 - 2000 | F8QT | 66 | 1870 |
MITSUBISHI LANCER V Station Wagon (CB_W, CD_W) |
||||
| 1.6 16V 4WD (CD4W) | 1992 - 2003 | 4G92 (SOHC 16V) | 83 | 1597 |
MITSUBISHI GALANT VI Stufenheck (E3_A) |
||||
| 1.8 (E32A) | 1987 - 1990 | 4G37 | 63 | 1755 |
| 1.8 (E32A) | 1987 - 1992 | 4G37 | 66 | 1755 |
| 1.8 Turbo-D (E34A) | 1987 - 1992 | 4D65 T | 55 | 1795 |
| 2.0 (E39A, E38A, E33A) | 1987 - 1992 | 4G63 (SOHC 8V) | 80 | 1997 |
| 2.0 4WD (E39A, E38A, E33A) | 1988 - 1992 | 4G63 (SOHC 8V) | 80 | 1997 |
| 2.0 GTi 16V (E39A, E38A, E33A) | 1987 - 1992 | 4G63 (DOHC 16V) | 106 | 1997 |
| 2.0 GTi 16V (E39A, E38A, E33A) | 1988 - 1992 | 4G63 (DOHC 16V) | 107 | 1997 |
| 2.0 GTi 16V 4WD (E39A, E38A, E33A) | 1988 - 1992 | 4G63 (DOHC 16V) | 106 | 1997 |
MITSUBISHI GALANT VI (E3_A) |
||||
| 1.8 (E32A) | 1988 - 1992 | 4G37 | 66 | 1755 |
| 1.8 Turbo-D (E34A) | 1988 - 1992 | 4D65 T | 55 | 1795 |
| 2.0 (E39A, E38A, E33A) | 1989 - 1992 | 4G63 (SOHC 8V) | 80 | 1997 |
| 2.0 4WD (E33A, E38A, E39A) | 1989 - 1992 | 4G63 (SOHC 8V) | 80 | 1997 |
| 2.0 GTI 16V (E39A, E38A, E33A) | 1988 - 1992 | 4G63 (DOHC 16V) | 106 | 1997 |
| 2.0 GTI 16V (E39A, E38A, E33A) | 1988 - 1992 | 4G63 (DOHC 16V) | 107 | 1997 |
| 2.0 GTI 16V 4x4 (E38A, E39A, E33A) | 1989 - 1992 | 4G63 (DOHC 16V) | 106 | 1997 |
MITSUBISHI GALANT VII Stufenheck (E5_A, E7_A, E8_A) |
||||
| 1.8 (E52A) | 1994 - 1996 | 4G93 (SOHC 16V) | 85 | 1834 |
| 1.8 GLSI (E52A) | 1992 - 1996 | 4G93 (SOHC 16V) | 93 | 1834 |
| 2.0 GLSI (E55A) | 1992 - 1996 | 4G63 (SOHC 16V) | 101 | 1997 |
| 2.0 GLSI 4WD (E75A) | 1992 - 1996 | 4G63 (SOHC 16V) | 101 | 1997 |
| 2.0 GLSTD (E57A) | 1992 - 1996 | 4D68 T | 66 | 1998 |
| 2.0 V6-24 (E64A, E54A) | 1992 - 1996 | 6A12 | 110 | 1999 |
MITSUBISHI GALANT VII (E5_A, E7_A, E8_A) |
||||
| 1.8 (E52A) | 1994 - 1996 | 4G93 (SOHC 16V) | 85 | 1834 |
| 1.8 GLSI (E52A) | 1992 - 1996 | 4G93 (SOHC 16V) | 93 | 1834 |
| 2.0 GLSI (E55A) | 1992 - 1996 | 4G63 (SOHC 16V) | 101 | 1997 |
| 2.0 GLSI 4WD (E75A) | 1992 - 1996 | 4G63 (SOHC 16V) | 101 | 1997 |
| 2.0 GLSTD (E57A) | 1992 - 1996 | 4D68 T | 66 | 1998 |
| 2.0 V6-24 (E64A, E54A) | 1992 - 1996 | 6A12 | 110 | 1999 |
MITSUBISHI SPACE RUNNER Großraumlimousine (N1_W, N2_W) |
||||
| 1.8 (N11W) | 1991 - 1999 | 4G93 (SOHC 16V) | 90 | 1834 |
| 1.8 (N11W) | 1996 - 1999 | 4G93 (SOHC 16V) | 85 | 1834 |
| 1.8 4WD (N21W) | 1991 - 1999 | 4G93 (SOHC 16V) | 90 | 1834 |
| 1.8 4WD (N21W) | 1996 - 1999 | 4G93 (SOHC 16V) | 85 | 1834 |
| 2.0 TD (N18W) | 1992 - 1999 | 4D68 T | 60 | 1998 |
MITSUBISHI SPACE WAGON (N3_W, N4_W) |
||||
| 1.8 (N31W) | 1991 - 1998 | 4G93 (SOHC 16V) | 90 | 1834 |
| 1.8 4WD (N41W) | 1991 - 1998 | 4G93 (SOHC 16V) | 90 | 1834 |
| 1.8 TD (N35W) | 1991 - 1998 | 4D65 T | 55 | 1795 |
| 2.0 (N33W) | 1992 - 1998 | 4G63 (SOHC 16V) | 98 | 1997 |
| 2.0 (N33W) | 1991 - 1997 | 4G63 (SOHC 8V) | 77 | 1997 |
| 2.0 4WD (N43W) | 1992 - 1998 | 4G63 (SOHC 16V) | 98 | 1997 |
| 2.0 TD (N38W) | 1992 - 1998 | 4D68 T | 60 | 1998 |
| 2.4 (N34W) | 1991 - 1997 | 4G64 (16V) | 88 | 2351 |
| 2.4 i (N34W) | 1992 - 1998 | 4G64 (16V) | 102 | 2351 |
MITSUBISHI GALANT VIII (EA_) |
||||
| 1.8 GDi (EA1A) | 1997 - 2001 | 4G93 (GDI) | 103 | 1834 |
| 2.0 (EA2A) | 1996 - 2000 | 4G63 (SOHC 16V) | 100 | 1997 |
| 2.0 GDI (EA7A) | 1997 - 2004 | 4G94 (GDI) | 107 | 1999 |
| 2.0 TDI (EA6A) | 1996 - 2004 | 4D68 T | 66 | 1998 |
| 2.5 V6 24V (EA5A) | 1996 - 2000 | 6A13 | 120 | 2498 |
| 2.5 V6 24V (EC5A) | 1996 - 2002 | 6A13TT | 206 | 2498 |
MITSUBISHI FTO Coupe (DE_A) |
||||
| 2.0 (DE3A) | 1994 - 2001 | 6A12 (DOHC) | 127 | 1999 |
MITSUBISHI GALANT VIII Kombi (EA_, EC_) |
||||
| 2.0 (EA2W) | 1996 - 2000 | 4G63 (SOHC 16V) | 100 | 1997 |
| 2.0 TDI (EA6W) | 1996 - 2003 | 4D68 T | 66 | 1998 |
| 2.5 V6 24V (EA5W) | 1996 - 2000 | 6A13 | 120 | 2498 |
| 2.5 V6 24V (EC5W) | 1996 - 2002 | 6A13TT | 206 | 2498 |
| 2.8 TD | 1996 - 2001 | 4M40-T | 92 | 2835 |
MITSUBISHI SANTAMO (UG) |
||||
| 2.0 16V | 1999 - 2004 | 4G63 (DOHC 16V) | 102 | 1997 |
| 2.0 16V 4WD | 1999 - 2004 | 4G63 (DOHC 16V) | 102 | 1997 |
MITSUBISHI SAPPORO III (E16A) |
||||
| 2.4 (E16A) | 1987 - 1990 | 4G64 (8V) | 91 | 2351 |
VOLVO |
||||
VOLVO S40 I (644) |
||||
| 1.6 | 1995 - 1999 | B 4164 S | 77 | 1587 |
| 1.8 | 1995 - 1999 | B 4184 S, B 4184 S3 | 85 | 1731 |
| 1.9 T4 | 1997 - 2000 | B 4194 T, B 4194 T2 | 147 | 1855 |
| 1.9 TD | 1995 - 1999 | D 4192 T | 66 | 1870 |
| 2.0 | 1995 - 2003 | B 4204 S, B 4204 S2 | 100 | 1948 |
| 2.0 | 1995 - 1999 | B 4204 S | 103 | 1948 |
VOLVO V40 Kombi (645) |
||||
| 1.6 | 1995 - 1999 | B 4164 S | 77 | 1587 |
| 1.8 | 1995 - 1999 | B 4184 S, B 4184 S3 | 85 | 1731 |
| 1.9 T4 | 1997 - 2000 | B 4194 T, B 4194 T2 | 147 | 1855 |
| 1.9 TD | 1995 - 1999 | D 4192 T | 66 | 1870 |
| 2.0 | 1995 - 2004 | B 4204 S, B 4204 S2 | 100 | 1948 |
| 2.0 | 1995 - 1999 | B 4204 S | 103 | 1948 |
