| Typ brzdového kotúča | s vnútorným chladením |
| Povrch | potiahnutá |
| Vonkajżí priemer [mm] | 281 |
| Hrúbka brzd. kotúča (mm) | 26 |
| Výżka [mm] | 44 |
| Ráfik, počet dier | 5 |
| Rozstupová krużnica Ø [mm] | 98 |
| Centrovací priemer [mm] | 59 |
| Kontrolná značka | ECE R90 APPROVED |
| Minimálna hrúbka (mm) | 24,2 |
| Hmotnosť [kg] | 6,90 |
| Rozmiestnenie otvorov/Počet otvorov | 10/5 |
| Značka | Číslo |
|---|---|
| A.B.S. | 18585 |
| AP | 25642 V |
| AP | 20145 V |
| ATE | 24.0126-0192.1 |
| BLUE PRINT | ADL144331 |
| BOSCH | 0 986 479 G82 |
| BRECO | BV 9421 |
| BREMBO | 09.5180.41 |
| COMLINE | ADC2975V |
| COMLINE | ADC2974V |
| DELPHI | BG4821C |
| EUROBRAKE | 5815312371 |
| FEBI BILSTEIN | 12037 |
| FERODO | DDF2776C |
| FIAT | 52017293 |
| FIAT | 52067394 |
| FIAT | 52017292 |
| FIAT | 52067393 |
| GIRLING | 6069331 |
| HELLA PAGID | 8DD 355 132-131 |
| JURID | 563274JC |
| MEYLE | 215 521 0006 |
| MINTEX | MDC2877C |
| MOTAQUIP | LVBD2025 |
| NK | 312371 |
| PILENGA | V1208 |
| RIDEX | 312371 |
| sbs | 1815312371 |
| Stark | SKBD-0020135 |
| SWAG | 70 91 2037 |
| TEXTAR | 92304803 |
| TRW | DF6933 |
| ZIMMERMANN | 230.2385.52 |
| ZIMMERMANN | 230.2385.50 |
| ZIMMERMANN | 230.2385.00 |
| Model | Rok | Kód motora | KW | CCM |
|---|---|---|---|---|
FIAT |
||||
FIAT TIPO Schrägheck (356_, 357_) |
||||
| 1.4 (356HXA1B) | 2016 - súčasnosť | 843 A1.000 | 70 | 1368 |
| 1.4 (356HXF1B) | 2016 - 2020 | 940 B7.000 | 88 | 1368 |
| 1.4 LPG (356HXF1B) | 2016 - 2020 | 940 B7.000 | 88 | 1368 |
| 1.6 (356HXE11) | 2016 - 2020 | 552 68 036 | 81 | 1598 |
| 1.6 D (356HXG1B, 356HXG11) | 2016 - 2020 | 552 60 384, 552 80 444 | 88 | 1598 |
FIAT TIPO Stufenheck (356_, 357_) |
||||
| 1.4 (356SXA1B) | 2015 - súčasnosť | 843 A1.000 | 70 | 1368 |
| 1.4 LPG (356SXF1B) | 2016 - 2020 | 940 B7.000 | 88 | 1368 |
| 1.6 (356SXE11) | 2015 - 2020 | 552 68 036 | 81 | 1598 |
FIAT TIPO Kombi (356_, 357_) |
||||
| 1.4 (356WXA1B) | 2016 - 2020 | 843 A1.000 | 70 | 1368 |
| 1.4 (356WXF1B) | 2016 - 2020 | 940 B7.000 | 88 | 1368 |
| 1.4 LPG (356WXF1B) | 2016 - 2020 | 940 B7.000 | 88 | 1368 |
| 1.6 (356WXE11) | 2016 - 2020 | 552 68 036 | 81 | 1598 |
| 1.6 D (356WXG1B) | 2016 - 2020 | 552 60 384, 552 80 444 | 88 | 1598 |
